microMAX Series

Features

·        20:1 Constant torque (TEFC):  1000:1 Constant Torque (TENV)

·        1.0 Service Factor on VFD

·        Low Operating temperature

·        Continuous duty at 40 C ambient

·        Class H insulation with CR200 Corona Resistant, 200 C rated magnet wire

·        Rolled steel frame construction

·        Foot-mounted with C-Face

·        UL Recognized and CSA Certified

·        Three-year warranty

·        Ranges from ¼ HP to 10 HP/1800 RPM/230/460 V/3 phase



BlueMAX Series

Features

·        1000:1 Constant Torque

·        1.0 Service Factor on VFD

·        Totally Enclosed, foot-mounted; C-Face as noted

·        Class H MAXGUARD insulation system

·        F1 standard, field reversible to F2

·        Encoder provisions included on opposite drive end

·        Ball bearings

·        Class F N/C thermostats

·        Cast iron construction

·        Continuous duty at 40 C ambient

·        UL Recognized and CSA Certified

·        Three-year warranty

·        Ranges from 1 HP to 350 HP/1800 RPM/230/460 V/3 phase



BlackMaX Series

Features

·        1000:1 Constant Torque

·        1.0 Service Factor on VFD

·        Totally Enclosed, foot-mounted; C-Face as noted

·        Class F MAXGUARD insulation system

·        F1 standard, field reversible to F2

·        Encoder provisions included on opposite drive end

·        Ball bearings

·        Class F N/C thermostats

·        Cast iron construction

·        Continuous duty at 40 C ambient

·        UL Recognized and CSA Certified

·        Three-year warranty

·        Ranges from 1/4 HP to 30 HP/1800 RPM/230/460 V/3 phase



Call us now at 862-377-0573 to match your VFD with the right motor.
